Predicting the Long-Term Creep Behavior of Wood and Plastic Pallets

Sakib Shadman

Sakib Shadman

Mohmmad Shadman Sakib
M.S. Student
shadmansakib@vt.edu

Find Sakib on LinkedIn here!



Biography:

Sakib Shadman

Research:

Sakib's article explaining his research project: "Pallets are often treated as secondary packaging, but in modern warehousing they function as structural components of the unit load. With the global pallet market currently around USD 92.18 billion, pallet performance has direct implications for product protection, warehouse safety, automation reliability, and supply chain efficiency. Wood still represents most of the pallet market, while plastic pallets are a growing segment because of their durability, reusability, and recyclability. Recent market estimates show the global pallet market near USD 92 billion in 2026, with wood holding the largest material share and plastic projected as one of the fastest-growing material categories.

My research focuses on the long-term creep behavior of wood and plastic pallets under static storage conditions. In warehouse storage, unit loads are commonly supported through two mechanisms: racking and floor stacking. In racking, the pallet span and top deckboard behavior become critical because the pallet must support the load across rack beams. In floor stacking, both the top and bottom deckboard systems are important because the pallet must transfer load through multiple contact interfaces. If the pallet deforms excessively under sustained loading, the unit load can become unstable, leading to product damage, load collapse, and safety hazards.

This is not only a performance issue but also a safety issue. A review of OSHA Severe Injury Report data for general warehousing over the last decade identified 26 severe injury cases involving workers being struck by falling objects. OSHA’s Severe Injury Reports include incidents such as in-patient hospitalization, amputation, or loss of an eye, and the public dataset is limited to federal OSHA jurisdiction, meaning the broader risk may be underrepresented. At static loading conditions, pallet failure can directly contribute to unstable unit loads; therefore, understanding pallet deformation over time is critical for both product protection and human safety.

When a pallet is subjected to sustained load, its components experience time-dependent deformation, known as creep. This behavior is especially important because pallet capacity is strength driven. A pallet may satisfy short-term strength requirements but continue to deform over days, months, or even a year of storage. Excessive creep can alter load distribution, reduce stiffness, disrupt pallet geometry, and compromise the stability of the entire unit load. This is increasingly important in automated warehouses, where AGVs and automated storage systems require consistent pallet dimensions and predictable handling performance.

The first objective of my research is to reduce the time required for current pallet testing standards by developing predictive models. Standards such as ASTM D1185 and ISO 8611 require multi-hour to multi-day testing and multiple samples to determine pallet load ratings. Reducing test duration would allow faster validation, faster product replication, lower testing cost, and more efficient use of laboratory resources. The second objective is to extend pallet performance evaluation beyond the standard test period. In practice, pallets may be stored under load for 30 days to one year, far longer than many standard tests. Directly testing every pallet design for these durations would require significant time, labor, and material. My research addresses this gap by predicting long-term pallet deflection from short-term experimental data.

The experimental design includes three main treatment factors: loading mechanism, material, and manufacturing method. The loading mechanisms are racking and floor stacking. The material groups are wood and plastic. For wood pallets, I am evaluating both block and stringer constructions. For plastic pallets, I am evaluating major manufacturing processes including injection molding, structural foam molding, rotational molding, compression molding, and thermoforming. Samples are tested for long-term creep behavior up to 30 days under controlled loading conditions.

To improve replicability and material efficiency, I validated a reduced pallet-section testing method, where a full pallet is reduced into a representative half-pallet section while preserving the critical load-bearing geometry. This approach allows more controlled testing, better replication, and improved material utilization. The creep load is scaled based on the effective load-bearing area relative to the full pallet, and deflection is measured using string potentiometers under constant load.

Using the experimental data, I am developing regression-based prediction models to estimate long-term pallet deflection from early-stage creep data. The current modeling framework uses first-order and second-order logarithmic models, where initial deflection data from a short training period are used to predict the deflection after 24 hours and 30 days. Preliminary results show that the model error stabilizes after approximately 4 hours, supporting the use of a 0.5–4 hour training window for long-term prediction. Across multiple materials, manufacturing methods, support conditions, and load applicators, the log-based models closely followed the experimental creep trends. The first-order log model has shown strong long-term stability, while the second-order model can reduce short-term bias in some cases.

Ultimately, this research aims to provide a faster and more practical way to evaluate pallet load ratings and long-term serviceability. Instead of relying only on destructive or extended-duration testing, the goal is to predict pallet creep behavior from short-term measurements with acceptable accuracy. If successful, this work can help pallet manufacturers, testing laboratories, and supply chain users reduce testing time, lower cost, improve safety margins, and design more reliable pallets for long-term warehouse storage."
